ADS-B aircraft tracking with readsb and tar1090
Rex's AIO package ships readsb and the tar1090 map as a disabled service with a menu launcher; Intercept or a hand-built dump1090 are the alternatives.
What it takes
- Software only
- Purchase required
Difficulty 1 of 3 — easy.
Details
With the AIO's RTL-SDR (or any dongle) on a 1090 MHz antenna, readsb decodes ADS-B and tar1090 draws the aircraft map in a browser. In Rex's hackergadgets-uconsole-aio-board package the service is disabled by default; the menu entry runs a script that starts readsb, opens tar1090 and stops both when you close it, because the dongle cannot be shared with SDR++.
Alejandro's Intercept install gets ADS-B alongside its other decoders, and the same thread has REDROBRC's Trixie problem — neither dump1090-fa nor dump1090-mutability would install from apt — resolved with a FlightAware discussion link and a build script.
Links
