MeshCore on the AIO v2: YAMPA, tui-meshcore and meshcore-uconsole
MeshCore has no Linux-native node firmware, so the community built on pyMC_core: guax's YAMPA packet analyser and TUI chat client, and cwill747's GTK app.
What it takes
- Software only
- Config change
- Purchase required
Difficulty 1 of 3 — easy.
Details
vileer's answer in October 2025 was that MeshCore did not support Linux-native devices; by February 2026 guax had a working stack on the AIO v2's SX1262 through pyMC_core and the pyMC_Repeater project. The board needs two extra lines in the sx1262 section — use_dio3_tcxo: true and use_dio2_rf: true — which interlock has since upstreamed as an AIO v2 preset (pyMC_Repeater PR #99). On top of that: YAMPA (GPLv3), a React front end over a Python WebSocket server started with server.py --radio-type uconsole; tui-meshcore (GPLv3, Textual), pip install -e . then tui-meshcore, for channels and direct messages; and cwill747's meshcore-uconsole, a GTK network analyser with hardware presets that installs from his APT repository as meshcore-uconsole.
All three share the radio, so stop meshtasticd first — LOCOSP's python-periphery errors on a CM5 were exactly that. cwill747 confirms the AIO v1 needs the same two settings.
Links
Open at Forum thread- GitHub — YAMPARepository
- GitHub — tui-meshcoreRepository
- Forum: TUI MeshCore clientForum
- GitHub — meshcore-uconsole (GTK)Repository
- pyMC_Repeater PR #99 — AIO v2 radio settingsRepository
- Forum: MeshCore with the HackerGadgets board (question thread)Forum
