Three-antenna bracket, one piece (David)
A single-piece remix of paragonnov's three-antenna bracket that prints as one part, so there is nothing to glue.
What it takes
- 3D print
- Disassembly
- Purchase required
Difficulty 2 of 3 — moderate.
Details
Published on MakerWorld in March 2025 as a remix of the two-piece bracket: the same three SMA positions and M4 mounting, printed as one part instead of being glued from two halves. Use paragonnov's thread for bolt lengths and antenna choices; nothing else changes.
