K7BAT uConsole Status App (Trixie, GTK3)
bryank7bat's GTK3 dashboard for Trixie: battery, temperature, storage, gpsd fix, Wi-Fi state, AIO v2 GPS/SDR/LoRa toggles and service restarts in one window.
What it takes
- Software only
Difficulty 1 of 3 — easy.
Details
A native GTK3 app for Debian 13 Trixie under labwc/Wayland (X11 desktops work too), installed from the release zip with chmod +x install.sh and sudo ./install.sh; the installer detects the desktop user, pulls dependencies and configures GPS if needed. It shows CPU temperature, RAM, storage and battery, gpsd fix, satellites, position, speed and heading, the Wi-Fi interface's mode, SSID, channel and signal, and — when an AIO v2 is fitted — on/off toggles with status for GPS, SDR and LoRa, service health with restart buttons and launcher buttons for navigation and SDR apps. The AIO v2 and AC1200 card are optional; the app runs without them.
v1.1.4 dates from 21 August 2026, and the thread tracks additions such as GPS app detection, SDR/GPS/Bluetooth hardware profiles and an ESP32 'sidekick' display driven over its API. WhyDev reports the GUI does not launch on Bookworm; the author was looking into it.
Links
Open at Forum thread- GitHubRepository
