Back cover for the EDATEC CM5 active cooler (remix)
Remix of the passive-cooler back that gives an EDATEC active cooler its height when the CM5 sits on the HackerGadgets adapter.
What it takes
- 3D print
- Disassembly
- Purchase required
Difficulty 2 of 3 — moderate.
Details
A remix that opens the cover for the EDATEC CM5 cooler's fan and fin stack while the module sits on HackerGadgets' adapter board, keeping the rest of the cover stock. Check fan clearance against your battery board before final assembly.
