Heatsink and thermal tape on the CM5
Two layers of 0.5 mm thermal pad and a small aluminium heatsink on the CM5 SoC, held with thermal tape — about 10 °C cooler under load.
What it takes
- Disassembly
- Purchase required
Difficulty 2 of 3 — moderate.
Details
bgav's recipe: two layers of ARCTIC TP-3 (0.5 mm) on the CM5's SoC, then a cut-down Easycargo 100 × 25 × 10 mm aluminium heatsink attached with 1-inch double-sided thermal tape. Nothing else changes and it fits under the stock back cover.
Reported result: roughly 60 °C under load before, low 40s at idle and about 51 °C under load afterwards.
